AquaPur Flex Concrete Injection

AquaPur Flex is a professional, flexible PU injection resin designed to stop water leaks in concrete. This hydro-reactive polyurethane concrete injection resin reacts with water and expands to form a waterproof, flexible PU foam. It is ideal for sealing cracks, joints and voids in concrete structures where movement may occur.

Thanks to its permanent elasticity, AquaPur Flex is particularly suitable for applications where rigid injection materials are insufficient. AquaPur Flex is supplied as a 2-component system (resin + accelerator), but can be processed using standard 1-component PU injection equipment.

Applications AquaPur Flex Concrete Injection

• Stopping active water leaks in concrete.
• Injecting concrete cracks.
• Sealing expansion joints and construction joints.
• Filling voids and seams.
• Concrete injection in cracks with structural movement.

AquaPur Flex is suitable for basements, foundations, tunnels, car parks and other concrete structures.

Key features

• Reacts with water and actively expands (hydro-reactive injection resin).
• Forms a flexible and waterproof polyurethane foam.
• Permanently elastic, even when the concrete moves.
• Waterproof up to 0.7 bar water pressure.
• Non-flammable.
• Excellent adhesion to concrete.
• Can be applied using 1-component PU injection equipment.
• Professional quality for durable concrete repair.

Directions for use

• Cracks and joints must be free of dust and loose particles.
• The presence of water in the crack is essential for proper foaming.
• Inject using suitable PU injection equipment.
• Place injection packers at 20–30 cm intervals.
• For vertical cracks, always inject from bottom to top.
• Clean equipment immediately after use with machine oil or a suitable solvent.

Specifications

Mixing ratio: 100:4 (by weight and by volume)
Product: flexible PU foam
Colour: white
Pot life: approx. 45 minutes (at 20°C)
Foam expansion ratio: approx. 1:10 (free expansion)
Foaming time at 20°C (30 g, 5% water):

• Start of foaming: approx. 24 seconds
• End of foaming: approx. 70 seconds

Density (free-foamed): approx. 62 kg/m³
Hardness: < 10 Shore A
Water absorption: high at low density (typical of hydro-reactive foams)
Substrate application temperature: +5°C to +40°C
Shelf life: 12 months from production date. Store between 10°C and 30°C

Packaging

Rayston AquaPur Flex injection grout is available as a complete 26 kg set (25 kg component A + 1 kg component B), ideal for smaller injection works. For larger concrete injection projects, AquaPur Flex is also available in 200 kg drums (component A) and 20 kg cans (component B). These are sold separately and not supplied as a set.

Do you have questions about the correct packaging or required quantity? Please feel free to contact our specialists for personalised advice.
