AquaPur Flex Concrete Injection
At a glance
- Flexible PU injection resin
- Water-activated
- For concrete injection
AquaPur Flex is a professional, flexible PU injection resin designed to stop water leaks in concrete. This hydro-reactive polyurethane concrete injection resin reacts with water and expands to form a waterproof, flexible PU foam. It is ideal for sealing cracks, joints and voids in concrete structures where movement may occur.
Thanks to its permanent elasticity, AquaPur Flex is particularly suitable for applications where rigid injection materials are insufficient. AquaPur Flex is supplied as a 2-component system (resin + accelerator), but can be processed using standard 1-component PU injection equipment.
AquaPur Flex is flexible and ideal for moving cracks, while AquaPur is semi-rigid and suitable for permanent water exposure in larger concrete structures.
Applications AquaPur Flex Concrete Injection
- Stopping active water leaks in concrete.
- Injecting concrete cracks.
- Sealing expansion joints and construction joints.
- Filling voids and seams.
- Concrete injection in cracks with structural movement.
AquaPur Flex is suitable for basements, foundations, tunnels, car parks and other concrete structures.
Key features
- Reacts with water and actively expands (hydro-reactive injection resin).
- Forms a flexible and waterproof polyurethane foam.
- Permanently elastic, even when the concrete moves.
- Waterproof up to 0.7 bar water pressure.
- Non-flammable.
- Excellent adhesion to concrete.
- Can be applied using 1-component PU injection equipment.
- Professional quality for durable concrete repair.
Directions for use
- Cracks and joints must be free of dust and loose particles.
- The presence of water in the crack is essential for proper foaming.
- Inject using suitable PU injection equipment.
- Place injection packers at 20–30 cm intervals.
- For vertical cracks, always inject from bottom to top.
- Clean equipment immediately after use with machine oil or a suitable solvent.
Specifications
Mixing ratio: 100:4 (by weight and by volume)
Product: flexible PU foam
Colour: white
Pot life: approx. 45 minutes (at 20°C)
Foam expansion ratio: approx. 1:10 (free expansion)
Foaming time at 20°C (30 g, 5% water):
- Start of foaming: approx. 24 seconds
- End of foaming: approx. 70 seconds
Density (free-foamed): approx. 62 kg/m³
Hardness: < 10 Shore A
Water absorption: high at low density (typical of hydro-reactive foams)
Substrate application temperature: +5°C to +40°C
Shelf life: 12 months from production date. Store between 10°C and 30°C
Packaging
Rayston AquaPur Flex injection grout is available as a complete 26 kg set (25 kg component A + 1 kg component B), ideal for smaller injection works. For larger concrete injection projects, AquaPur Flex is also available in 200 kg drums (component A) and 20 kg cans (component B). These are sold separately and not supplied as a set.
Do you have questions about the correct packaging or required quantity? Please feel free to contact our specialists for personalised advice.
Product properties
The key technical properties clearly listed in one place.
- Article number
- POL002297
-
Hardness describes a material's resistance to indentation. For silicone rubber and other elastomers, the Shore A scale is commonly used: Shore A 15, for example, is softer than Shore A 40. Harder plastics may be rated on the Shore D scale. The number belongs to its Shore scale and is not a unit like MPa; values on different scales cannot be directly compared.
- Shore A < 10
-
The period for which an unopened product remains usable under the specified storage conditions. Check whether the period starts from the manufacturing date or another date. Shelf life may be shorter after opening, especially for products sensitive to air or moisture.
- 12 months
-
Mixing ratio indicates how much of each component is needed, for example resin (A) and hardener (B). A ratio of 100:50 by weight means 100 grams of A to 50 grams of B; by volume you might use millilitres. Weight and volume ratios are not necessarily the same because the components may have different densities. Accurate measuring is important for proper curing.
- 100:4 (by weight and volume)
-
Working time is the period during which a product remains workable after mixing or activation, usually given in minutes at a specified temperature, often 20 °C. With reactive resins, the chemical reaction also continues in the mixing container, and larger quantities or higher temperatures can shorten this time. Working time is different from gel time and full curing time.
- Approximately 45 minutes (at 20 °C)
Safety information
Read the warnings and use appropriate protective equipment before handling the product.
